Monitor Open Frame Touchscreen 10.1-inch Elo 1093L E321195
416,24 € incl. VAT
Elo 1093L E321195 – touch monitor (open-frame, 16:9 (widescreen)), screen size: 25.7 cm (10.1”), projected capacitive, 1280×800 pixels, response time: 25ms, contrast: 800:1, VGA, display-port, HDMI, touch interface: USB, incl.: cable (USB, VGA, HDMI), must be ordered separately: power cable, power supply, color: black
Elo 1093L E321195 10.1-inch Open Frame Touchscreen Monitor
Compact, precise and perfect for integration into professional systems
Elo 1093L is a 10.1-inch (25.7 cm) open-frame monitor, specially designed for industrial, commercial and medical applications.
With Projected Capacitive (PCAP) touch technology, 1280×800 resolution and HDMI, DisplayPort and VGA connectivity, this model offers reliable performance and precise touch interaction in a compact format.
Thanks to its slim and robust design, the 1093L is ideal for interactive kiosks, POS, HMI equipment and information terminals.
⚙️ Technical Specifications
| Specification | Technical Details |
|---|---|
| Model | Elo 1093L (E321195) |
| Screen Type | Open-frame Touchscreen |
| Touch Technology | TouchPro® Projected Capacitive (PCAP) |
| Diagonal Size | 10.1” / 25.7 cm |
| Native Resolution | 1280 × 800 pixels (16:10) |
| Typical Brightness | 315 cd/m² |
| Contrast | 800:1 |
| Refresh Time response | 25 ms |
| Viewing angle (H/V) | 85° / 170° |
| Mounting | VESA 75 × 75 mm, open-frame support |
| Video interfaces | VGA, DisplayPort, HDMI |
| Touch interface | USB Type-B |
| OS Compatibility | Windows, Linux, Android |
| Case Color | Black |
| Operating Temperature | 0°C – 40°C |
| Lifetime (MTBF) | 50,000 hours |
| Package Included | USB, HDMI, VGA |
| Optional accessories | power cable, DC power supply |
🌟 Bright screen and excellent clarity
The 10.1-inch screen offers a clear image, with 315 cd/m² brightness and optimal contrast of 800:1, perfect for indoor applications.
LED backlight technology ensures natural colors and low power consumption, and the wide viewing angle (170°) guarantees readability from any position.
🧠 Touch precision and durability PCAP
TouchPro® PCAP (Projected Capacitive) technology enables precise and responsive multi-touch, up to 10 simultaneous points, similar to modern smartphone screens.
This technology ensures high reliability, minimal maintenance and a natural, fluid and stable user experience even in intensive 24/7 applications.
🔌 Complete connectivity and universal compatibility
The Elo 1093L model includes a full range of modern ports:
- HDMI – for high-quality digital signal
- DisplayPort – for industrial compatibility
- VGA – for legacy systems
- USB (Type-B) – for touch connection
The monitor is plug & play and compatible with Windows, Linux and Android, without the need for additional drivers.
🧩 Open-frame design for flexible integration
The open-frame construction and VESA 75×75 mm mounting system allow installation in:
- interactive kiosks and POS,
- industrial control panels (HMI),
- medical devices,
- payment machines,
- ticketing terminals or infotainment.
With a compact design and metal side profiles, integrators can quickly incorporate the monitor into custom enclosures or touch panels.
⚙️ Key Benefits
- 🔹 Precise PCAP touch (up to 10 simultaneous points)
- 🔹 Full connectivity: HDMI, DisplayPort, VGA, USB
- 🔹 315 cd/m² brightness – excellent indoor clarity
- 🔹 Rugged design, tested for 24/7 operation
- 🔹 Compatible with Windows, Android and Linux
- 🔹 Flexible VESA 75×75 and open-frame mounting
- 🔹 International Certifications (CE, UL, FCC, TUV, UKCA)
🧰 What’s in the Box
- Elo 1093L Monitor
- USB Cable (Touch)
- HDMI Cable
- VGA Cable
- Quick Setup Guide (QSG)
👉 Power cord and power adapter must be ordered separately.
Elo 1093L 10.1″ Open Frame Touchscreen offers the ideal combination of touch precision, industrial reliability, and compact design.
With PCAP technology, universal connectivity, and 24/7 performance, this model is the perfect choice for integrators, manufacturers of kiosks, HMI applications, and interactive commercial solutions.
Reliable, durable, and easy to integrate – the Elo 1093L is a reliable partner for any professional project.
