Datalogic GRYPHON GFS4500 GFS4520-BKK1-WHT scanning modules
440,00 € 211,02 € incl. TVA
Datalogic GFS4520-BKK1-WHT – OEM kit 2D megapixel, white illumination, microUSB 5V, IP54. Includes scanner + USB cable for quick integration.
Only logged in customers who have purchased this product may write a review.
Product description
Datalogic Gryphon GFS4520-BKK1-WHT – OEM Kit 2D Megapixel, USB, White Illumination
Datalogic Gryphon GFS4520-BKK1-WHT is part of the GFS4500 Fixed Series range, being designed for OEM applications such as self-service kiosks, ticket validators, POS terminals, access systems or medical equipment.
With 1MP (1280 × 800 px) sensor, white LED illumination and Blue Dot aimer, this module provides 1D/2D omnidirectional scanning, support for OCR and reading from mobile screens.
The package (kit) includes the GFS4520-BK-WHT module and the original USB cable (94A051968), for quick integration via USB micro at 5V.
Key Features – GFS4520-BKK1-WHT
📦 Complete Kit: GFS4520-BK-WHT scanner + USB cable (94A051968)
📷 1MP megapixel sensor for advanced reading and image capture
💡 White LED illumination (WHT) – better performance on colored backgrounds
🎯 Blue Dot aimer for fast and precise aiming
🌟 Visual and audible feedback: Green Spot + front LED + adjustable beeper
📱 Reading from mobile phones and displays (QR, tickets, electronic coupons)
⚡ Scanning speed: 60 fps, motion tolerance: 70 IPS
🛡️ IP54 protection, dust, splash and disinfectant resistance
🌐 USB-only connectivity (microUSB), 5V – simplified integration
Technical specifications – Gryphon GFS4520-BKK1-WHT
| Category | Specifications |
|---|---|
| Model | GFS4520-BKK1-WHT |
| Package (Kit) | Scanner GFS4520-BK-WHT + USB cable 94A051968 |
| Technology | 1MP megapixel imager (1280 × 800 px) |
| Illumination | White LED (WHT) + Blue Dot aimer |
| Codes Supported 1D, 2D (QR, DataMatrix, Aztec, Han Xin), PDF417, OCR, Digimarc, postal codes Maximum resolution 1D: 3 mils; Data Matrix/PDF417: 5 mils Frame rate 60 fps Motion tolerance 70 IPS Reading angles Pitch: ±60°; Roll: 180°; Skew: ±60° | |
| Interfaces | USB-only (microUSB) |
| Power supply | 5 VDC |
| Consumption | <225 mA îin operation; ~115 mA standby |
| Protection | IP54 |
| Dimensions | 2.8 × 4.8 x 5.5 cm |
| Weight | 52 g |
| Case | Black |
| Certifications | RoHS, IEC 62471 (LED Risk Group 1) |
| Warranty | 5 years factory warranty |
👉 Datalogic Gryphon GFS4520-BKK1-WHT is the “plug & play” package; for OEMs who want 2D megapixel scanning with white illumination, ideal for retail, healthcare and kiosks.
https://youtu.be/9KUEh4W_yyI
