CAB XD Q 4/300 dual-side label printer 6011500

XD Q4/300 dual-side label printer

XD Q4/300 dual-side label printer – Industrial Label Printer for Top Demands

With the XD Q4/300 dual-side label printer, you will revolutionize the way you manage your labeling. This industrial printer is equipped with advanced features and a print resolution of 300 DPI, ensuring that every label is precise and of high quality.

Exceptional Performance and Maximum Flexibility

With a print speed of 125 mm/s, the XD Q4/300 Printer is ideal for your fast production requirements. The thermal transfer (TT) and direct thermal (DT) printing method allows printing on a wide range of materials, including textile tapes, cardboard labels, identification tapes and heat shrink tubes.

Detailed Control and Efficiency

One of the outstanding features of this printer is the ability to assign heating to each print head separately. This way, you can optimize the print quality for each project. The XD Q4/300 Printer also features a media guidance system to ensure precise printing, especially for continuous and thin materials. An integrated separator helps separate the continuous material from the ribbon, improving feeding accuracy.

Ribbon Saving and Continuous Printing

With this printer, you will save ribbon when printing only on the top side of the material using print head 2. Print head 1 is automatically raised, and the ribbon is stopped by an electromechanical brake during the material advance. The XD Q4/300 printer also ensures continuous printing without label loss when cutting or perforating labels.

Advanced Technical Specifications

• Printing Resolution: 300 DPI
• Interface: USB + LAN (Ethernet 10/100)
• Memory: 64 MB RAM / 8 MB FLASH
• Maximum Label Width: 110 mm
• Maximum Label Roll Diameter: 300 mm
• Maximum Ribbon Width: 114 mm
• Maximum Ribbon Length: 360 m
• Supported Barcodes: 1D and 2D, including Code 39, Code 128, Data Matrix, QR-Code and many more
• Compact Dimensions: 395 mm x 554 mm x 248 mm
• Weight: 21 kg

Versatile Use and Reliability

The XD Q4/300 dual-side label printer is suitable for a variety of applications, from textile labeling to the production of labels for cables and heat-shrinkable tubes. With a compact Flash slot and WLAN slot, you can expand the functionality of this printer to suit your specific requirements.

The XD Q4/300 printer is equipped with a Real Time Clock (RTC) for data storage and can operate in temperatures ranging from 10°C to 35°C, ensuring that it can cope with various working environments.

Invest now in the XD Q4/300 dual-side Label Printer and benefit from maximum performance, flexibility and efficiency in your labeling process. With this top-of-the-line printer, you will achieve superior quality results for your labeling projects.
