Bluetooth BLE scanner KOAMTAC KDC280

Bluetooth BLE scanner KOAMTAC KDC280

KOAMTAC KDC280 is a compact Bluetooth barcode scanner designed for mobile applications in retail, logistics, warehouse, field and service. The series is available in three scanning versions – laser , CCD and imager – so it can cover different requirements, from fast reading of 1D codes to scanning of 2D codes in modern workflows. The small size and light weight make it a practical choice for users who need high mobility and comfortable operation throughout the day.

One of the important advantages of the KDC280 series is its scanning flexibility. The laser and CCD variants are dedicated to 1D codes, while the imager variant reads both 1D and 2D codes. Depending on the scanning engine and code type, the maximum reading distance reaches up to 190 mm for the laser version, 300 mm for the CCD version and 246 mm for the imager version. Thus, the series can be easily adapted to the final application and working environment.

The KOAMTAC KDC280 scanner offers modern connectivity via Bluetooth Low Energy and Micro USB , making it suitable for integration with smartphones, tablets, PCs, smartwatches, smart glasses and other smart devices. The 1-inch OLED screen and 3-button design simplify interaction and provide clear feedback during use. In addition, the 8 MB internal memory and 64 KB RAM allow for the storage of a large number of barcodes and support useful functions for data collection.

The KDC280 series is built for professional use. It features a 650 mAh Li-Ion battery, easy to replace, charging via Micro USB or cradle, and IP65 protection against dust and water jets. The rugged housing withstands drops of up to 1.5 meters, making this scanner suitable for demanding environments. For companies looking for a reliable, compact and versatile portable scanner, the KOAMTAC KDC280 is an efficient and easy-to-integrate solution.

• Series available in laser, CCD and imager variants
• 1D or 1D/2D reading, depending on model
• Bluetooth Low Energy and Micro USB interface
• 1-inch OLED screen and 3-button design
• Memory 8 MB Flash and 64 KB RAM
• 650 mAh Li-Ion battery, replaceable
• IP65 protection and 1.5m drop resistance
• Compatible with Android, iOS, Mac OS X, Windows and Tizen
