Open Frame Touchscreen Monitor 31.5″ PCAP Touch 30 points, Full HD, Anti-Glare – iiyama TF3215MC-B2AG
1.145,87 € incl. VAT
The IIYAMA TF3215MC-B2AG is a 31.5” Open Frame touchscreen monitor with 30-point PCAP technology, edge-to-edge AG glass, foam-sealed mounting and IP65 front protection – ideal for interactive kiosks, industrial environments and public applications.
IIYAMA ProLite TF3215MC-B2AG – 32” PCAP Touchscreen, Open Frame, Through-Glass, for retail, kiosk & wayfinding
iiyama ProLite TF3215MC-B2AG is a 31.5” Open Frame touchscreen with PCAP technology (10 points) and Anti-Glare edge-to-edge glass, designed for retail, self-service kiosks, wayfinding, hospitality and corporate spaces. The Open Frame construction with side mounting allows for clean integration into furniture and totems, and Through-Glass maintains interactivity even behind a glass plate (ideal for display cases). The Full HD, 500 nits IPS panel offers stable colors and excellent visibility, and the front with IP65 protection, 7H tempered glass and design for 24/7 operation ensures reliability in demanding public environments.
Why choose TF3215MC-B2AG
- PCAP 10-touch + Through-Glass: precise touches with a finger, stylus or glove; also works through glass.
- 500 nits IPS panel: clear image, wide viewing angles and consistent colors in any position.
- Open Frame with side mounting: elegant integration into furniture, totem, interactive table or wall.
- Protected front (IP65) & 7H glass: dust/splash resistance and heavy use in public spaces.
- Full connectivity: HDMI/DP/VGA, USB for touch, LAN/RS-232C for network control.
- 24/7 & free orientation: landscape, portrait or face-up – non-stop operation for professional projects.
Recommended scenarios
- Retail & QSR: self-order, digital catalogs, interactive “through-glass” windows, dynamic menus.
- Wayfinding & public: info-kiosk, interactive maps, ticketing, building guidance.
- Corporate & huddle: interactive tables, feedback terminals, briefing boards.
Technical specifications
| Section | Specifications |
|---|---|
| Panel / Image | Diagonal 31.5” (80 cm); IPS LED technology; 1920×1080 @60Hz (Full HD, 16:9); brightness 500 cd/m²; contrast ~1200:1; ~8 ms GTG response time; 178°/178° viewing angles; ~NTSC 72% gamut; 698.4 × 392.8 mm viewable area; 0.363 mm pixel pitch; Anti-Glare edge-to-edge glass. |
| Touch (PCAP) | Projected Capacitive, 10 points; Through-Glass (operation through glass); palm rejection; methods: finger, glove, capacitive stylus; touch interface USB (HID). |
| Video Inputs | HDMI ×2 (up to 1080p@60Hz); DisplayPort ×1; VGA ×1. |
| Outputs / Audio | Audio out 3.5 mm; (integrated speakers – depending on configuration). |
| Control & Network | RS-232C (Get/Set), LAN (RJ45) for management; IR (optional, where applicable). |
| Features | Auto Source / FailOver, DDC/CI, OSD/IR lock for public spaces, anti-image retention. |
| Operation & Environment | 24/7; landscape / portrait / face-up orientation; usual operating temperature 0…40 °C. |
| Protection & Mechanical | IP65 on front; 3 mm tempered glass, 7H hardness; Open Frame with side mounting; metal casing (matte black). |
| Mounting | VESA 200×200 mm + side mountings for integration; table/totem/furniture compatible. |
| Power & Consumption | Internal power supply; AC 100–240 V, 50/60 Hz; typical consumption ~50–60 W, stand-by ~0.5 W. |
| Dimensions & Weight | Panel dimensions ~746 × 441 × 60 mm; net weight ~12–14 kg; delivered in a box with protections. |
| In the box | Power cable, USB (touch), HDMI, Open Frame side mounting set, guides. |
| Conformity | CE, CB, TÜV-Bauart, EAC, RoHS, ErP, WEEE, REACH, UKCA. |
“The combination of PCAP 10-touch, Through-Glass and Open Frame makes the TF3215MC-B2AG an extremely versatile solution for self-service projects.”
Benefits at a glance
- Premium touch experience: PCAP 10-touch, smooth writing, palm rejection.
- Easy integration: Open Frame with side mounts and VESA 200×200.
- Safe in public spaces: 7H glass, IP65 front, OSD/IR lock.
- Rich connectivity: HDMI/DP/VGA + USB touch, LAN/RS-232C control.
- Non-stop: designed for 24/7 and free orientation.
Frequently Asked Questions (FAQ)
1) Can it work behind glass in a display case?
Yes, Through-Glass technology maintains touch functionality through a glass plate (within specified limits).
2) Is it suitable for 24/7?
Yes, it is designed for continuous operation and public environments.
3) What type of mounting does it support?
It has Open Frame and VESA 200×200 side mounts, ideal for furniture and totems.
4) What connections does it have for video sources?
It includes HDMI, DisplayPort and VGA, plus USB for touch connection.
5) Does it have dust and splash protection on the front?
Yes, the front is IP65 with 7H tempered glass.
6) Can I lock the controls in public spaces?
Yes, you have OSD/IR lock and management options via LAN/RS-232C.
