Monitor Touchscreen 15.6″ Open Frame Full HD PCAP 10 Touch, IPS, HDMI/DP – iiyama TF1633MSC-B1
474,32 € incl. VAT
IIYAMA TF1633MSC-B1 15.6” PCAP open frame touchscreen monitor with 10 touch points, Full HD resolution, edge-to-edge glass, IPS panel, IP54 protection, ideal for retail and kiosk solutions.
IIYAMA ProLite TF1633MSC-B1 – Open-frame 15.6” touchscreen, PCAP 10-touch, Full HD, edge-to-edge anti-glare/anti-fingerprint glass, for kiosk, retail & interactive displays
iiyama ProLite TF1633MSC-B1 is a 15.6” (Full HD) open-frame touchscreen designed for self-service kiosks, interactive displays, POS/retail and info-kiosk. PCAP 10-touch technology provides fast and precise touch, and edge-to-edge glass with anti-glare/anti-fingerprint treatment ensures good visibility and easy cleaning. HDMI / DisplayPort / VGA connectivity plus USB for touch (HID) simplifies integration with PCs and media players, and the open-frame format allows for clean mounting in furniture or totems. Designed for 24/7 operation and landscape/portrait/face-up orientation, the TF1633MSC-B1 is a reliable solution for high-traffic projects.
Why choose TF1633MSC-B1
- Open-frame for “invisible” integration – clean mounting in totems, walls or custom furniture.
- PCAP 10-touch – fluid gestures (tap, swipe, pinch/zoom, rotate) with finger, capacitive stylus or thin glove.
- Edge-to-edge glass – anti-glare/anti-fingerprint for readability and quick sanitization.
- Universal connectivity – HDMI, DisplayPort, VGA + USB touch (HID plug-and-play).
- Designed 24/7 – reliable for public spaces; OSD key-lock for protection.
Recommended scenarios
- Retail & QSR: self-ordering, interactive catalogs, dynamic menus on totems.
- Showcases & interactive signage: behind-glass campaigns, interactive promotions.
- Receptions & hospitality: check-in/out, wayfinding, self-service info counters.
- Public/education/museums: ticketing, questionnaires, compact interactive installations.
Technical specifications
| Section | Specifications |
|---|---|
| Model | ProLite TF1633MSC-B1 |
| Panel / Image | 15.6” (39.6 cm) • IPS/ADS • 1920×1080 @60 Hz (16:9) • panel brightness ≈300–400 cd/m² (slightly lower with touch layer) • contrast ≈1000:1 • response time ≈8 ms GTG • viewing angles ≈178°/178° • 16.7 million colors • edge-to-edge glass with Anti-Glare finish |
| Touch (PCAP) | 10 points (HID) • methods: finger, capacitive stylus, thin glove • palm-rejection • USB interface |
| Inputs / Outputs | HDMI ×1 • DisplayPort ×1 • VGA ×1 • USB (type B) ×1 for touch • Audio-out 3.5 mm |
| OSD & Security | OSD key-lock, DDC/CI, image presets; button lock option |
| Orientation & Mounting | Landscape / Portrait / Face-up • Open-Frame format for integration • VESA 100×100 mm |
| Operation & Reliability | Designed for 24/7; typical operating temperature 0…40 °C |
| Power & Consumption | External adapter, DC 12 V • typical consumption ≈10–18 W • stand-by ≈1–2 W |
| Useful dimensions | Active area ≈344 × 194 mm • pixel pitch ≈0.179 mm • slim profile for concealed mounting |
| In the package | Power, USB (touch), HDMI (and/or DP cables according to market); cable management elements; start-up guide |
| Compliance | CE, RoHS, ErP, WEEE, REACH, UKCA |
“Open-frame + PCAP 10-touch = clean integrations, ‘smartphone-like’ experience and reliability for continuous use.”
Benefits at a glance
- Discreet integration with open-frame chassis and VESA 100×100.
- Precise touch on a compact 15.6” Full HD format.
- Universal connectivity (HDMI/DP/VGA + USB touch).
- 24/7 thinking, with lock functions for public spaces.
Frequently Asked Questions (FAQ)
1) Is it suitable for mounting in a totem?
Yes, the open-frame format is designed specifically for integration into totems/furniture.
2) Does it work with gloves?
Yes, with thin gloves; also with capacitive stylus and finger.
3) What PC/OS is compatible?
Any PC/SoC with HDMI/DP/VGA; the touch works HID plug-and-play on Windows, Android, Linux.
4) Can it be used in portrait mode?
Yes, it supports landscape/portrait/face-up, depending on the project.
5) Is it protected for public spaces?
Yes, OSD key-lock and easy-to-clean anti-glare/anti-fingerprint glass.
6) What sound does it offer?
Audio-out for external solutions; some configurations include speakers for basic signaling.
7) What is the typical consumption?
Around 10–18 W, efficient for continuous operation.
8) Is there a VESA mount?
Yes, VESA 100×100 mm, useful for integration, service or jigs.
