105” 5K UHD ultra-wide interactive display with 21:9 widescreen and PureTouch-IR⁺ touch – IIYAMA TE10518UWI-B1AG
8.413,13 € incl. VAT
IIYAMA TE10518UWI-B1AG 105” panoramic interactive display with 5K UHD resolution, PureTouch-IR⁺ technology, Android 13, USB-C, microphone and 16W speakers + subwoofer.
IIYAMA ProLite TE10518UWI-B1AG – 105” 5K UHD 21:9 Interactive Display for Large Meeting Rooms & Front Row
iiyama ProLite TE10518UWI-B1AG is a 104.6” (265.7 cm) ultra-wide interactive touch screen with 5K (5120×2160) resolution in 21:9 format, designed for modern collaboration in large meeting rooms, classrooms, training and hybrid spaces. The high-quality VA panel (450 cd/m²) and anti-glare (AG) glass with PureTouch-IR+ deliver natural and precise writing with up to 40 touch points (32 for writing), palm rejection and ±1 mm accuracy. The Android 13 (iiWare 11) platform brings whiteboarding, multi-OS wireless sharing and centralized management, while the latest connectivity (HDMI 2.1, DP 1.4, USB-C with Power Delivery up to 100 W) ensures easy and scalable setup. For meetings, the 21:9 format is ideal for Microsoft Teams Front Row, providing increased visibility for content, chat and participants.
Why choose TE10518UWI-B1AG
- 21:9 panoramic frame for Front Row: extra-wide workspace for multiple windows, perfect for hybrid meetings and “meeting equity”.
- 5K UHD on 105″: fine details on a large surface – complex presentations, dashboards, side-by-side applications.
- Natural writing & anti-glare: PureTouch-IR+, 3 mm AG glass, 7H hardness, palm rejection – for quick notes and clean annotations.
- All-in-one connectivity: HDMI 2.1, DP 1.4, USB-C (front 15 W; rear 100 W PD with video+touch), HDMI out, LAN IN/OUT, RS-232C, OPS.
- Built-in audio & voice capture: 2×16 W + 16 W subwoofer and 8-array microphone with up to ~8 m capture – clear meetings without additional hardware in many scenarios.
- Android 13 (iiWare 11) embedded system: whiteboard, WPS Office, iiyama Share/EShare, Wi-Fi 6, DMS management.
- Built-in for professional use: 16/7, fanless design, ambient light sensor, OSD lock, case metal, 5-year warranty.
“A good display makes ideas easier to see, understand, and discuss.”
Recommended scenarios
- Boardrooms & large training rooms: Front Row at ideal scale, sharing via USB-C “one cable” or wireless.
- Advanced education & auditoriums: fluid writing, multi-touch, Android 13 apps, and fast connection of student laptops.
- Control rooms & technical projects: 5K/21:9 for simultaneous viewing of multiple sources and dashboards.
Technical specifications
| Section | Specifications |
|---|---|
| Panel / Image | Diagonal 104.6” (265.7 cm); panel type VA; resolution 5120×2160 (5K UHD, 21:9); brightness 450 cd/m²; 4000:1 contrast (5000:1 dynamic); 6.5 ms GTG response time; 178°/178° viewing angles; 10-bit, 1.07 billion color space (NTSC 90%); 0.479 mm pixel pitch; 2450 × 1033.6 mm viewable area (96.5 × 40.7”). |
| Glass / Touch | AG (anti-glare) glass, zero bonding; 3 mm thickness; 7H hardness; PureTouch-IR+ technology; 40 points (32 pt writing, HID); ±1 mm accuracy; methods: stylus, finger, glove; palm rejection: yes; USB touch interface. |
| Video inputs | HDMI ×4 (1× 2.1 up to 5120×2160@60 Hz; 3× 2.0 up to 3840×2160@60 Hz YUV444); DisplayPort 1.4 ×1 (up to 5120×2160@60 Hz); USB-C ×2 (3.2 Gen1, 3840×2160@60 Hz, DP Alt 1.2, Touch; front 15 W PD, rear 100 W PD). |
| Video / Audio Outputs | HDMI out ×1 (3840×2160@60 Hz, YUV/RGB444); USB-C out ×1 (3.2 Gen1, 3840×2160@60 Hz, DP Alt 1.2, Touch, 5 W PD, MSD – Multi-Screen Display); audio: Optical S/PDIF ×1, 3.5 mm jack ×1. |
| USB / Network & Control | USB ×8 (front: 2× USB-A 3.2 Gen1, 1× USB-C 15 W; rear: 2× USB-A 3.2 Gen1, 1× USB-C 100 W; top: 2× USB-A 3.2 Gen1); RJ45 LAN ×2 (IN/OUT, auto-switch PC & Android, 1000 Mb); RS-232C ×1; HDCP 2.3 (HDMI/DP/USB-C). |
| Audio & Microphone | Speakers 2×16 W + subwoofer 16 W (front); 8-array microphone, capture approx. 8 m. |
| Integrated system | iiWare 11 (Android 13): iiyama DMS/OS, iiyama Class, Notes, browser, file manager, cloud drives, WPS Office, iiyama Share & EShare (Windows/iOS/Android); Wi-Fi 6 (OWM002); hardware: CPU A311D2 (A76×4 + A55×4, 2.4 GHz), GPU Mali G610, RAM 8 GB, ROM 64 GB. |
| Features | Kiosk fashion, red. blue light, anti-image retention, media playback, Plug&Play DDC2B, OSD key lock, max. 16/7 operating time, landscape orientation, fanless design. |
| Mounting & Dimensions | VESA 1000×400 mm; metal housing; dimensions 2507.2 × 1130.1 × 103 mm; net weight 91.4 kg; box dimensions 2668 × 1305 × 280 mm; gross weight 119.5 kg. |
| Consumption / Power | Internal power supply; AC 100–240 V, 50/60 Hz; 282 W typical, 0.5 W standby, 0.3 W off. |
| Package Contents | Remote control (with batteries), 4× stylus (dual tips, antibacterial), power/USB/HDMI cables, Wi-Fi 6 Module (OWM002), wall mount (VESA 1000×400), NUC mount, webcam mount, guides. |
| Compliance / Other | CB, CE, TÜV-Bauart, EAC, RoHS, ErP, WEEE, REACH; MTBF 50,000 h (without backlight); EAN 4948570122011; compatible accessories: OPS Slot PC; 5-year warranty. |
Key benefits at a glance
- Huge 105” screen with 5K for excellent readability in large rooms.
- One-cable connection via USB-C 100 W: charge, stream video and touch at the same time.
- Front Row-ready (21:9): more space for content and participants.
- Integrated sound with subwoofer + 8-array microphones: clearer, more natural meetings.
- Android 13 & Wi-Fi 6: whiteboard, presentations, mirroring, management.
- Robust and reliable: 16/7, fanless, metal housing, 5-year warranty.
Frequently asked questions (FAQ)
1) Can I use Front Row from Microsoft Teams?
Yes, the 21:9 format is ideal for Front Row and hybrid scenarios.
2) Can I connect my laptop with a single cable?
Yes, via USB-C (up to 100W PD on the rear port) with video, data, and touch.
3) What is the audio power?
2×16 W system + 16 W subwoofer front-facing – enough for medium-large rooms.
4) What accessories are included?
Remote control, 4 styluses, main cables, Wi-Fi 6 module, VESA 1000×400 wall mount, NUC stand and webcam stand.
5) Does it have a modular PC slot?
Yes, there is a slot for OPS Slot PC.
6) What is the warranty policy?
5 years (depending on the country and manufacturer’s conditions).
7) Can it be used 24/7?
It is recommended for 16/7 (16 hours a day, 7 days a week).
8) What network options does it have?
LAN IN/OUT (1 Gbps), Wi-Fi 6, plus DMS management on Android 13.
